B0505S-1W 5V to 5V Converter DC DC Power Module Converter

Specification:-

• Voltage (input): 5V ±10% DC
• Voltage (output): 3.3V ±10% DC
• Max. Power (W): 1
• Maximum Efficiency (%): 70 to 79
• Output Current (A): 0.2 to 0.3
• Linear adjustment rate: ±1.2%
• Load regulation rate (10%-100%): 15%
• Short circuit protection 1S, automatic recovery
• Working temperature: -45~85°C
• Noise/Ripple :‰¤75mVp-p (Nom.), ‰¤100mVp-p (Max.)
• MTBF ‰¥ 200 million hours
• Max capacitive load: 220uF
• Dimensions (mm): 11.7 x 6 x 10

Features:

• High power density
• Up to 86% efficiency
• Operating temperature range: -40°C to +105°C
• Small SIP / DIP package
• International standard pin mode
• Isolation voltage 1000VDC
