The 7404 is a high-speed CMOS Logic Quad NOT Gate. 7404 contains Six independent NOT gates in one package. The NOT gate consists of only one input and one output. A NOT gate is used to output the Boolean inverse of the applied input. Hence the name ‘Digital Inverter’ or ‘Inverting buffer’. The most commonly used NOT gate IC is 7404.

7404 Features and Specifications

• Supply voltage range: +4.75V to +5.25V
• Maximum supply voltage: +7V
• Maximum current allowed to draw through each gate output: 8mA
• Totally lead-free
• MaximumRise Time: 15ns
• Maximum Fall Time: 15ns
• Operating temperature:0°C  to 70 °C

Applications

• General-purpose logic
• Servers
• Memory units
• PCs and notebooks
• Digital Electronics
• Networking
• Digital systems
